DBLDBL V6 Heat Press: Six Station, Double Heat Press, Rotating, Automatic Pneumatic Heat Press (SIX STATIONS, each 16 inches x 20 inches)

1 year replacement

$14,899.99

$17,899.99 SAVE 17%

The DBLDBL V6 (SIX STATION) Heat Press by DTFPRO is here!

This is the DBLDBL V6, a work-horse and one of the most reliable and durable heat presse automation solutions on the market, comparable to heat presses that are more than double its price tag. This pneumatic heat press is used offers fast heat recovery, accurate temperature, even pressure and an ability to achieve consistent results under high capacity use. This is a pneumatic, automatic machine that can be used to heat press fabric, cloth, posters, mouse pads, and more. It can be operated in fully automatic, or manual modes. This machine provides steady performance and long life expectancy. Featuring SIX STATIONS, each 15.75 inches x 19.7 inches.

The design of the four station presses combines a heavy-duty solid industrial grade pressing framework with high quality electric components. This provides the operator with the best possible features and equipment needed for today's various heat transfer applications. The desired settings can be set easily with the temperature controller. The pneumatic pressure can be regulated smoothly with the air reducing valve. With the restriction valve on the solenoid valve, the press and lift speed can also be adjusted.

Features:

• Digital timer and temperature controller
• Press and lift speed adjustment controls
• Pressure balancing system on heat plate and bottom plate
• Operates in automatic or manual modes
• Adjustable air pressure by air reducing valve
• CE certificated and RoHS certificated

Specifications:

• Temp range: 0-260 Celcius (500 F)
• Machine dimensions & weight: 1912*1655*1400mm; 380kg
• Packing dimensions & weight: 2000*1150*1520mm; 490kg
• Voltage: 220V single phase
• Power: 5700w; 26amps

NOTE: Color may vary, typically cream, black, gray or white. Orders are shipped on first ordered, first shipped basis. Standard air compressor required (not included).

Item #: DTF-PRO-DBLDBL-V6
